Alternatives to Texas Instruments ADC12DJ5200RFEVM

Texas Instruments ADC12DJ5200RFEVM and its qualified second sources, compared on form, fit and function, stock, lifecycle and price — the same checks Parter runs inside a BOM.

Equivalent and substitute parts for Texas Instruments ADC12DJ5200RFEVM

ADC12DJ5200RFEVM compared against its qualified second sources
ADC12DJ5200RFEVMTexas InstrumentsADC12DJ5200SEEVMTexas Instruments1208-ADCDJ5200EVMTexas Instruments+2more
FFF CompatibilityPlugs into the identical FMC+ host carrier card (e.g., TSW14J57EVM) using the exact same VITA-57.4 connector pinning.The physical board layout, mounting holes, and high-speed data interface footprint match the original evaluation module.Utilizes the ADC12DJ5200SE which delivers equivalent sampling rates and resolutions, though it features an integrated single-ended input balun rather than external transformer-coupling.Features the identical VITA-57.4 FMC+ connector interface for host system coupling.Follows the standard high-speed converter EVM form factor and footprint.Provides the exact same 12-bit 10.4 GSPS ADC functionality, with the addition of the TRF1208 active driver in the analog input signal chain.
AI Summary

ADC12DJ5200RFEVM by Texas Instruments: ADC12DJ5200RF - 12 Bit 10.4G Samples per Second Analog to Digital Converter (ADC) Evaluation Board.

This is a direct sister evaluation module designed to evaluate the single-ended input version of the ADC. It is a drop-in option for system-level evaluation.

  • Maintains the same high-speed 12-bit, 10.4 GSPS single-channel / 5.2 GSPS dual-channel performance baseline
  • Uses the identical FMC+ connector interface and is fully compatible with the TSW14J57EVM data capture board and High-Speed Data Converter Pro software
  • Integrated internal balun simplifies RF input design and cabling requirements
  • Analog input interface is optimized for single-ended signals via the internal balun instead of passive transformer-coupled differential signaling

This evaluation board features the same ADC12DJ5200RF converter but pairs it with an active TRF1208 differential amplifier on the front end. It is ideal for evaluating active signal chain solutions.

  • Evaluates the exact same ADC12DJ5200RF converter chip as the queried board
  • Includes an active TRF1208 fully-differential amplifier (FDA) to evaluate active driver performance rather than passive transformers
  • Maintains identical FMC+ digital interface and software support
  • Analog front-end includes an active amplifier, which introduces active power consumption and noise parameters not present on the passive transformer-coupled original EVM
Lifecycle StatusActiveActiveActive
Market AvailabilityIn stockIn stockIn stock
REACHREACHREACHUnknown
RoHSRoHSRoHSRoHS
——— ————————— ——— ———————— ———————— ————— ———
—————— ————————— ————————— ——— ———————— ——————
———— ————— ————— —————————— ————————— ——— ————
—— ————————— ———————— ————— —————————— ————
——— ————————— ——— ———————— ———————— ————— ———
—————— ————————— ————————— ——— ———————— ——————
———— ————— ————— —————————— ————————— ——— ————
—— ————————— ———————— ————— —————————— ————
